Urban sludge compost tank
Can treat river sludge, sewer sludge, etc. and turn it into organic fertilizer through fermentation
Share with
Advantages and characteristics
Parameter information
Product atlas
Parts introduction
Scope of application
Advantages and characteristics
Advantages and characteristics
A design and development team that strives for perfection
Tank closed
Tank closed
Thermal Insulation
Polyurethane insulation
Drive Processing
Hydraulic drive
Energy Saving Settings
Heat exchangeprocessing system
Long Life
304 anti-corrosionstainless steel
Easy To Use
Electrical control
Parameter information
Parameter Information
A design and development team that strives for perfection
Tank diameter (mm) Tank height (mm) Tank volume height (mm) Minimum floor area (M2)
5500 8440 3900 55
Tank volume (M3) Bottom bolwer (kW.h) Treatment capacity (m3 / day)
(including 50-70% water content)
Output (m3 / day)
(about 30% water content)
86 11*2 7~10 3~4.5
Power Supply 380V50Hz
Daily water consumption m³ (kW.h)
Hopper volume Hydraulic station (kw)
380V50Hz 1 1.35 7.5+2.2
Lnudced draft fan(kW.h) Spry Tower(kW.h) Auxiliary heater(kW.h) Discharge device(kW.h)
3 1.5 4 2.2
Installed Power 40.9 Operating power(kW.h)
43.5 About 25
Tank diameter (mm) Tank height (mm) Tank volume height (mm) Minimum floor area (M2)
6000 8440 3900 60
Tank volume (M3) Bottom bolwer (kW.h) Treatment capacity (m3 / day)
(including 50-70% water content)
Output (m3 / day)
(about 30% water content)
102 12.5*2 8~12 4~5
Power Supply 380V50Hz
Daily water consumption m³ (kW.h)
Hopper volume Hydraulic station (kw)
380v50Hz 1 1.35 7.5+2.2
Lnudced draft fan(kW.h) Spry Tower(kW.h) Auxiliary heater(kW.h) Discharge device(kW.h)
3 1.5 4 2.2
Installed Power 40.9 Operating power(kW.h)
46.5 About 27
Tank diameter (mm) Tank height (mm) Tank volume height (mm) Minimum floor area (M2)
6000 9000 4500 60
Tank volume (M3) Bottom bolwer (kW.h) Treatment capacity (m3 / day)
(including 50-70% water content)
Output (m3 / day)
(about 30% water content)
102 12.5*2 8~14 4~5
Power Supply 380V50Hz
Daily water consumption m³ (kW.h)
Hopper volume Hydraulic station (kw)
380v50Hz 1 1.35 7.5+2.2
Lnudced draft fan(kW.h) Spry Tower(kW.h) Auxiliary heater(kW.h) Discharge device(kW.h)
3 1.5 4 2.2
Installed Power 40.9 Operating power(kW.h)
46.5 About 27
Product atlas
Product Atlas
The whole equipment structure is divided into three parts
Parts introduction
Parts Introduction
The whole equipment structure is divided into three parts

The lower base part is distributed with hydraulic stations, scroll air pumps, oil cylinders, heating systems and stirring shafts, etc.; the middle part is a double-layer insulated tank, equipment automatic control system, export device, etc. The inner wall of the tank is lined with 304 stainless steel. Effectively prolong the life of the tank and reduce the residual clinkerThe lower base part is distributed with hydraulic stations, scroll air pumps, oil cylinders, heating systems and stirring shafts, etc.; the middle part is a double-layer insulated tank, equipment automatic control system, export device, etc. The inner wall of the tank is lined with 304 stainless steel, effectively prolong the life of the tank and reduce the residual clinker. There is an insulation layer filled with polyurethane foaming agent in the middle, and the outer wall is made of thickened steel plate to support the tank. The upper part is composed of shelters, detection platforms and exhaust facilities. The ancillary equipment includes automatic tipping bucket elevator, exhaust gas filtering and deodorizing system and heat exchange system device.

Livestock and husbandry manure compost tank
Upper part
Scope of application
Scope Of Application —Raw Material
The whole equipment structure is divThe whole equipment structure is divided into three partsided into three parts
Mushroom residue
Municipal sludge
Crop straw
Livestock manure
Livestock and poultry carcasses
Operation Principle
for erosion control, mine restoration, oilfield reclamation, dust control, landfill cover,landscaping, golf courses, turf, etc.
